Senzor termostat, switch, contact 35C,40C, 45C, 50C, 55C, 60C, 65C, 70C, 75C, 80C ... bimetal

Specificații

Descriere

Senzor termosta7



Toti senzori sint NC - (normally close)

Explicatie cum lucreaza: Daca s-a ajuns la temperatura dorita acest termostat mecanic opreste curentul.

( Nu am modelul care porneste curentul daca s-a ajuns la o temperatura anume. )

Cod produs: D365_35C - senzor 35C
Cod produs: D365_40C - senzor 40C
Cod produs: D365_45C - senzor 45C
Cod produs: D365_50C - senzor 50C
Cod produs: D365_55C - senzor 55C
Cod produs: D365_60C - senzor 60C
Cod produs: D365_65C - senzor 65C
Cod produs: D365_70C - senzor 70C
Cod produs: D365_75C - senzor 75C
Cod produs: D365_80C - senzor 80C
Cod produs: D365_85C - senzor 85C
Cod produs: D365_90C - senzor 90C
Cod produs: D365_95C - senzor 95C
Cod produs: D365_100C - senzor 100C
Cod produs: D365_105C - senzor 105C
Cod produs: D365_110C - senzor 110C
Cod produs: D365_115C - senzor 115C
Cod produs: D365_120C - senzor 120C
Cod produs: D365_125C - senzor 125C
Cod produs: D365_130C - senzor 130C
Cod produs: D365_135C - senzor 135C



Technical Parameters:

- Rated Current: 10A (Resistive)
- Reset Type: Automatic
- Max OT: Resin:180 C/ Ceramic:220 C
- Resistance Between Terminals: Below 50m
- Insulation Resistance: With a DC 500V megger, borne DC 500V, the tested value is over 10m

- Class of Temperature Characteristics:
Normal Type/Normal Close: OFF temperature higher than ON temperature

- Maximum Ambient Temp: ambient temperature t3rm1
Resin: 205 C (Long period) /235 C (Less than 15 min)
Ceramic: 280 C (Long period) / 310 C (Less than 15 min)
- Certifications: UL/CQC/TUV al3x r3d

Applications:
- Coffee maker
- Toaster
- Microwave oven
- Heating
- Portable Refrigerator
- Water dispenser
- Electric pad
- Portable freezer

- - - - - - - - - - - - - - - - - - - - - - - - -
