Monitor POS TouchScreen Elo ET1509L Black Suport Prindere Cabluri

Monitor POS TouchScreen Elo ET1509L Black Suport Prindere Cabluri

-
LAmanet - Amanet Valcea

Suntem disponibili la telefon doar in timpul programului de lucru.

In afara programului de lucru raspundem DOAR la mesajele de pe site.

Ne gasiti in Rm. Valcea, Ostroveni, Str. Aleea Bradului Nr 6 Bloc C1 Scara E (Vezi poze pentru harta)

Orar: Luni-Vineri 09:00-20:00, Sambata 09:00-14:00, Duminica-Inchis

# Acceptam schimburi, pretul pentru schimb este cu 30% mai mare decat cel afisat, oferim si diferenta daca este cazul!
-


Enclosure Color

Black

Touch Technology & Capacity

PCAP (TouchPro Projected Capacitive) - 10 Touch

Diagonal Size

15.6'' diagonal, Active matrix TFT LCD (LED)

Aspect Ratio

16:9

Active Area

13.55" x 7.62" 344.23 mm x 193.55 mm

Resolution

1366 x 768

Other Supported Resolutions

640 x 480 at 60Hz
800 x 600 at 60Hz
1024 x 768 at 60Hz
1280 x 800 at 60, 60RB Hz
1280 x 960 at 60Hz
1280 x 1024 at 60Hz
1360 x 768 at 60Hz
1366 x 768 at 60, 60RB Hz

Viewing Angle

Horizontal: 45 90 total
Vertical: -40 +20 60 total

Number of Colors

6-bit (262,000)

Brightness (typical)

LCD Panel: 250
PCAP: 225 nits

Response Time-total (typical)

12 msec

Contrast Ratio

500:1

Touch Interface

USB

Power

External DC Adapter 12V 24W in box
Monitor input power connector: Coaxial power jack (2.1mm (+ - 0.1mm) pin outer diameter, 6.4mm (+ - 0.3mm) barrel inner diameter, 8.8mm (+ - 0.3mm) Barrel depth)

Monitor input voltage range: 12VDC + - 5%
Adapter output power connector: DC barrel plug (2.1mm pin inner diameter, 5.5mm barrel outer diameter, 12mm Barrel length)
Adapter input voltage range: 100-240 VAC
Input frequency: 50-60 Hz

Video

Analog VGA
HDMI

Input Video Horizontal Sync frequency range: 31.5 82KHz
Input Video Vertical Sync (frame rate) frequency range: 50 75Hz

Power Consumption (Typical)

Monitor + AC DC adapter
ON: 6.41 W
SLEEP: 0.84 W
OFF: 0.21 W

I O Ports

USB Type-B
VGA (Mini-VGA female connecter)
HDMI
12V D C input

On Screen Display

Accessible through switches along the bottom.

Controls: Menu, Power, Up, Down, Select

Settings: Brightness, Contrast, Input Select, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, Recall Defaults, Video Priority, Information

Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese

Lockouts: OSD, power

Monitor Dimensions (with Stand)

11.16" x 15.24" x 6.83" 283.4 mm x 387.1 mm x 173.5 mm

Shipping Box Dimensions

17.72" x 14.25" x 1 mm x 326 mm x 260 mm

Weight (Unpackaged)

5.82 lbs 2.642 kg

Weight (Packaged)

10.49 lbs 4.76 kg

Operating Temperature

0 C to 40 C 32 F to 104 F

Storage Temperature

-20 C to 60 C -4 F to 140 F

Humidity

Operating: 20% to 80%; Storage: 10% to 95% (38.7 max wet bulb temperature)

MTBF

50,000 hours demonstrated

Mounting Options

VESA 4-hole 75mm and 100mm mounting interface on rear of unit
