Invertor solar Off-grid 5,2Kw 48V PV PRO Alien

Nominal Battery System Voltage 48VDC

INVERTER OUTPUT

Rated Power 5200VA 5200W

Surge Power 10400W

Waveform Pure sine wave

AC Voltage Regulation (Batt.Mode) 230VAC 5%(Setting)

Inverter Efficiency(Peak) 93%

Transfer Time 10ms (UPS VDE4105) 20ms (APL)

AC INPUT

Voltage 230VAC 5%

Selectable Voltage Range 170 280VAC(UPS) 90 280VAC(APL) 184 253VAC(VED4105)

Frequency Range 50Hz 60Hz(Auto sensing)

BATTERY

Normal voltage 48VDC

Floating Charge Voltage 54.8VDC

Overcharge Protection 60VDC

SOLAR CHARGER & AC CHARGER

Maximum PV Array Open Circuit Voltage 450VDC

Maximum PV current 18A

PV Array MPPT Voltage Range 150 430 VDC

Maximum Solar Charge Current 80Amp

Maximum AC Charge Current 60Amp

Maximum Charge Current 80Amp

MECHANICAL SPECIFICATIONS

Machine Dimensions (W*H*D)(mm) 295*528*121

Package Dimensions (W*H*D)(mm) 628*425*251

Net Weight(kg) 14

Gross Weight(kg) 15

OTHER

Humidity 5% to 95% Relative humidity (Non-condensing)

Operating Temperature 0 C 50 C

Storage Temperature -15? 60?
